Our range of Fire
Hydrants Systems are
standard fire detection system that
can easily sense fire in the initial
stage and can control it by
automatically dialing the fire
brigade station or other related
authority and inform. To control the
fire an optional automatic Carbon
Di-Oxide discharger
can also help. Fire Hydrant System
is one of the most effective fire
alarming systems.
The whole pipeline is kept under
uninterrupted pressure with water.
Whenever the hydrant valve is open,
the pressure in the pipeline reduces
drastically and jockey pump set
which normally keeps the total
system pressurized is unable to cope
with the system demand which results
in further fall in pressure. The
further fall in pressure is
perceived by the designated pressure
switch and the main fire pump set
starts automatically. Relying upon
the type and sensitivity of the
risk, diesel-engine powered fire
pump set should also be installed
having standby capacity of 100%.
Some of the system components of
fire.
It is a semi-automatic fire
extinguishing system. A network of
pipes is laid out counting upon the
risk with hydrant valves placed at
strategic places. The spacing or the
distance between yard hydrants is
guided by norms viz.
Pipes, Special Nozzles, Fire Hoses,
Monitors, Hose Boxes, Hose Reel
Drums etc.
|
|
|
|
Hydrant
Valves |
|
|
|
 |
Single Headed Oblique
Type Gun Metal Fire
Hydrant Valve 2.5"
(63mm), 75mm N.B.
Flanged inlet,
with 63mm Female
inst. Outlet with
Blank Cap and Chain
as per IS:5290 with
ISI mark (Flange
O.D 200mm, PCD
160mm, 4 nos X 19mm
dia holes) (Also
available in
Stainless Steel)
|
* 63mm
GM
Single
Headed
Hydrant
Valve –
Commercial
(Flange
O.D
185mm,
ID 63mm,
PCD
145mm)
|
|
* Also
available
in 38mm,
50mm –
Standard
Quality
(GM)
|
|
|
|
|
 |
|
Double
Headed Gun
Metal
Hydrant
Valve 2.5"
(63mm) with
two
individually
controlled
63mm Female
Inst.
outlets,
with 100 mm
N.B. Flanged
Inlet,
complete
with male
Blank Caps
and
Chains
as per
IS:5290
(Flange OD
220 mm, PCD
180mm, 8 nos
X 19mm dia
holes)
|
|
|
|
Double Headed Hydrant Valve – Commercial (Flange OD 220mm, ID 100mm, PCD 180mm)
|
|
|
|
|
|
|
|
Top
|
|
Branches & Nozzles |
|
|
|
 |
Short Branch Pipe
Gun Metal 63mm with
Detachable Hexagonal
Nozzle as per IS:903
with ISI Mark (Also
available in
Stainless Steel or
Aluminium or Copper)
Also available in
38mm, 50mm –
Standard Quality –
GM, Aluminium
|
|
|
|
 |
|
Water/Foam
Nozzle –
produce
secondary
aspirated
(sometimes
non
aspirated)
foam which
have
expansion
ratio of 1:3
to 1:4 with
Female BSP
Thread
Inlet.
|
|
|
|
MONITOR NB
|
FLOW lpm
|
RANGE* (Mtrs)
|
|
|
|
Water
|
Foam
|
|
63
|
1880
|
5
|
44
|
|
75
|
2820
|
62
|
51
|
|
100
|
3760
|
72
|
61
|
|
150
|
7520
|
87
|
73
|
|
|
|
|
|
 |
FAST ACTION NOZZLE
– Dual
pressure fire
fighting nozzle,
lightweight, made of
aluminium extrusion,
hand controlled,
anodized for
resistant of
corrosion and wear,
having arrangement
for detent flows, to
shut off pressure
assistance flush
without shutting
down, slide type
valve for turbulence
free flow moulded
rubber, teeth for
full fill, power for
gasket gribber inlet
screen, pistol type
grip for holding,
flow straightness
for quality jet
stream and knob
provision for
switching from
standard 100 PSI to
emergency low
pressure operation,
suitable for flow of
900 lmp at 7 kg/cm2
with inlet of 63mm
size. Weight 3.2 kg
approx.
|
|
|
|
 |
AQUAJET MULTIPUPOSE
NOZZLE – pistol-grip
fire fighting,
hand-held nozzle
made out of light
weight alu. Alloy
duly hard-anodised
with solid bore tip
and additional
advantage of fog
pattern at the same
time. Nozzle 2 ½ “
(M) inst. / 1 ½ “
(F) thread / 2 ½ “
(F) thread. Approx.
weight 2.25 kg.
|
|
|
|
 |
SUPERFIRE MULTI
GALLONAGE NOZZLE /
UNILITE –Fire
fighting nozzle,
made of extruded
all. Alloy hard
anodized for
resistance to
corrosion and wear.
Select ‘O' metic
mode provides
variable flow rates
at 7 kg/cm2,
360-475-600-750 and
900 lpm and flush
without shutting
down. Spinning teeth
ring form water
curtain for cooling
and operator's
protection from
heat. Ball valve
operated flow
control lever for
shutting off. Inlet
with 63mm male inlet
conforming to
IS:903, Piston grip
for greater control
|
|
|
|
 |
NUELITE NOZZLE – Professional
fire fighting nozzle
made of die-cast,
al. alloy, having
arrangement for
constant flow at
straight jet/wide
angle fog and
complete shut-off,
with a pistol-grip,
ball type shut-off
valve with
adjustable seat &
suitable for flow of
400 lpm at 7 kg/cm2
with inlet of 63mm
size conforming to
IS:903
|
|
|
|
 |
MEDIUM
VELOCITY SPRAY
NOZZLE
– Made of Brass or
SS with ½” BSPT end
connections.
K-factor: Metric -
22,30,35,41,51,64,79,
91 & 102
Spray angle -
65°,80°,90°,100°,110°,120°
& 140°
|
|
|
|
 |
HIGH
VELOCITY SPRAY
NOZZLE –
Made of Brass with
¾” BSPT end
connections.
K - Factor & Spray
angle: Metric - K18
x 80°, K22x75°,
K26x100°, K 32x 90°
|
|
|
|
 |
Fog Nozzle
(G.M.)
having arrangement
of jet, high
pressure fog and
complete shut off
with 63mm male inst.
Inlet, duly
chromplated as per
IS: 952.
Also available in
38mm
|
|
|
|
 |
Triple
Purpose Nozzle
(G.M.)
(Universal branch
pipe) having
arrangement of jet,
fine spray and
shutoff with 63mm
male inst. Inlet,
duly chromplated as
per IS: 2871
Also available in
38mm |
|
|
|
 |
London Pattern (Hand
Controlled) Nozzle (G.M.)
having arrangement
of Jet, Spray,
Adjustable water
curtain and shutoff
with 63mm male inst.
Inlet, duly
chromplated. |
|
|
|
 |
Revolving Nozzle (G.M.)
with 63mm male inst.
Inlet duly
chromplated as per
IS:906 (Flange
Connection also
available) |
|
|
|
 |
Multi Purpose Spray
Nozzle (G.M)
for Water / Foam
Spray having
arrangement of Jet,
fine spray, fog,
complete shutoff
with adjustable flow
output with 63mm
male inst. Inlet
duly chromplated.
(ELKHART DESIGN) |
|
|
|
 |
Jumbo / Mayura
Curtain Nozzle capable
of giving 180 deg.
Curtain spray to 20'
to 25' feet height
with 63mm G.M. male
inst. Inlet. |
|
|
|
 |
Diffuser Nozzle (G.M.)
Navy Type Nozzle
with 63mm Male or
Female inlets having
arrangement of Jet,
spray and shutoff |
|
|
|
|
|
Top
|
|
Delivery Coupling & Hose |
|
|
|
 |
C.P.
(Controlled
Percolating) HOSE
- Cotton/Synthetic
Fibre, Circularly
Woven Jacketted
Controlled
Percolating Fire
Hose, treated
against rot with
mystox, 36 kg/cm2
burst pressure,
22kg/cm2 proof
pressure as per
IS:8423 with ISI
mark.
Sizes 50mm (2”),
63mm (2.5”)
|
|
|
|
 |
RRL
(Reinforced
Rubberlined) Fire
Hose Type A
- Cotton Synthetic
Fibre, circularly
Woven Jacketed
Rubberized Fabric
RRL Fire Hose,
treated against rot
with mystox 36
Kg/cm2 burst
pressure, 22kg/cm2
proof pressure as
per IS:636:88 type A
with ISI Mark.
Sizes 38mm (1.5”) ,
50mm (2”), 63mm
(2.5”), 70mm (2. ¾
“)
|
|
|
|
 |
RRL Fire
Hose Type A
- Non-percolating
Fire Hose with outer
jacket made from
100% high tenacity
synthetic yarn,
lined with seamless
EPDM having 38kg/cm2
Burst pressure, 22
Kg/Cm2 Proof
Pressure and
18KG/cm2 working
pressure as per
IS:636/1988 Type ‘A'
ISI mark. (MAGMEX
Brand)
Sizes 38mm
(1.5”),50mm(2”),63mm(2.5”),70mm(2.
¾ “) |
|
|
|
 |
RRL
(Reinforced
Rubberlined)
EXTOCOAT -
Fire Hose with outer
special Elastomeric
coating, circular
woven Jacketed, 100%
High tenacity
Synthetic Yarn inert
against mildew and
rot lined with a
special compound of
synthetic rubber
with 40 Kg/cm2 burst
pressure, 22kg/cm2
proof pressure as
per IS:636:88 Type A
with ISI Mark.
Sizes 38mm
(1.5”),50mm(2”),63mm(2.5”),70mm
(2. ¾ “)
|
|
|
|
 |
RRL
(Reinforced
Rubberlined)
Fire Hose
Type B Non
Percolating Fire
Hose Completely
composite
construction
circularly woven 3
layered synthetic
jacketed fully
encapsulated with a
specially formulated
elastomer, resistant
against grease,
oils, acids, ozone,
fungus, alkalies,
heat and other
chemicals with outer
design to facilitate
a good grip,
completely flexible
and lightweight, no
maintenance with
42Kg/cm2 burst
pressure, 25kg/cm2
proof pressure,
18kg/cm2 working
pressure as per
IS:636:88 type B
with ISI mark.
Sizes
38mm(1.5”),50mm(2”),63mm(2.5”),
70mm (2. ¾ “) |
|
|
|
 |
High
Pressure Fire
Fighting Hose
seamlessly woven
with high grade
synthetic yarns with
EPDM rubber lining
to ensure high
protection against
ozone and rot with
burst pressure of
50kg/cm2 & proof
pressure of 36
kg/cm2 as per
IS:14933-2001 Type
‘A' with ISI Mark
(INFERMEX Brand)
Sizes
38mm(1.5”),50mm(2”),63mm(2.5”),
70mm (2. ¾ “)
|
|
|
|
 |
High
Pressure Fire
Fighting Hose
with special inert
compound for higher
degree of protection
against corrosive
chemicals, heat and
ozone suitable for
high pressure
applications with
burst pressure 50
kg/cm2 as per
IS:14933-2001 Type-B
with ISI Mark.
(C-JET Brand)
Sizes
38mm(1.5”),50mm(2”),63mm(2.5”),
70mm (2. ¾ “) |
|
|
|
 |
Delivery
Hose coupling male &
female Gun
Metal 2.5"(63mm),
inst. type 63mm X
63mm size as per IS:
903 with ISI mark.
(Also available in
Stainless Steel or
Aluminium or Copper)
Also available in
38mm, 50mm –
Standard Quality –
GM, Aluminium |
|
|
|
 |
Suction
Coupling
Gunmetal 4” Male &
Female Round
Threaded as per
IS:902. (Available
in 3” also)
Also available in
standard quality |
|
|
|
 |
Rubber
Suction Hose
- blend of natural /
synthetic rubber
compound with wire
embedded between the
reinforcement with
corrugated outer
layer as per IS:3549
with ISI Mark. (Type
1: WP-7 kg/cm2, Type
2: WP-10kg/cm2)
Size: 3” or 4” or 6” |
|
|
|
 |
Suction
Strainer Gunmetal
4” having
Female Round Thread
as per IS:907 (Also
available in 3”)
Also available in
standard quality |
|
|
|
|
|
Top
|
|
Hydrant Accessories |
|
|
|
 |
Single Hose Box -
Wall mounting type
in 600mm X 400mm X
250mm) size to
accommodate 1
lengths of 7.5 mtr.
or 15 mtr. or 30 mtr.
hoses and a branch
pipe with glass
covered single door
with lock and key
arrangements.
Available in MS or
FRP
|
|
|
|
 |
Double Hose Box -
Wall mounting type
in 750mm X 600mm X
250mm size to
accommodate 2
lengths of 7.5 mtr.
or 15 mtr. hoses and
a branch pipe with
glass covered double
door with lock and
key arrangements
Available in MS or
FRP For 30mtr. – 2
Lengths (Size 1200mm
x 625mm x 250mm) |
|
|
|
 |
Hose Reel
Drum,
swinging wall
mounting type made
of mild steel sheet
to accommodate 30mtr
or 36.5mr of 19mm
dia Rubber Hose with
nozzle along with
suitable bracket for
fixing on the wall.
Nozzle – ABS or
Gunmetal or
Aluminium Available
with 24mm Hose also. |
|
|
|
 |
Rubber Hose
for Hose Reel Drum
– Made of natural /
synthetic rubber
with plain or
corrugated finish as
per IS:444 with ISI
Mark (Type 1: WP-6
Kgf/cm, Type 2:
WP-10 Kgf/cm)
Size: 19mm or 24mm
O.D. (Also available
in Commercial
Quality Double
Braided) |
|
|
|
 |
Air Release
Valve - GM
25mm Male threaded
air release valve. |
|
|
|
|
|
Top
|
|
Monitors |
|
|
|
 |
Superjet Water
Monitor –
Stand Post Type made
out of IS:1239
Seamless Steel
tubes, Hot dip
galvanized, flanged
inlet, G.M. Ball
bearings Swivel
joints with brass
locking
arrangements,
permitting 360 deg.
Horizontal, 80-45
deg. Vertical
traverse, with
Aluminium Alloy
Nozzle with male
threaded inlet as
per IS:8442 with ISI
Mark. (Available
in GM Nozzle or with
63mm G.M. Female
inst. Outlet)
|
MODEL
|
OPERATINGPRESSURE
RANGEKg/cm2
|
INLET
FLANGE
NB
|
PERFORMANCE*(at
7 Kg/cm2
pressure)
|
|
FLOWlpm
|
RANGEMtrs
|
|
63MM
|
6 - 12
|
75 OR
100
|
1750
|
55
|
|
75MM
|
6 - 12
|
100
|
2580
|
62
|
|
100MM
|
7 - 12
|
150
|
3750
|
67
|
|
|
|
|
 |
|
Superjet
Water/Foam
Monitor –
Stand Post
Type made
out of
IS:1239
Seamless
Steel tubes,
Hot dip
galvanized,
flanged
inlet, G.M.
Ball
bearings
Swivel
joints with
brass
locking
arrangements,
permitting
360 deg.
Horizontal,
80-45 deg.
Vertical
traverse,
with
Aluminium
Alloy Foam
Nozzle with
pickup tube
as per
IS:8442 with
ISI Mark.
|
|
MODEL
|
OPERATINGPRESSURE RANGEKg/cm2
|
INLET FLANGE NB
|
PERFORMANCE*(at 7 Kg/cm2 pressure)
|
|
FLOWlpm
|
RANGEMtrs
|
|
63MM
|
7
|
75
|
1750
|
50
|
|
75MM
|
7
|
100
|
2580
|
60
|
|
100MM
|
7
|
150
|
3500
|
64
|
|
|
|
|
|
 |
GROUND MONITOR – made
of light weight
(18kg) aluminium
alloy with nozzle
for waterjet and
universal nozzle for
waterjet, fog, foam.
Universal joint for
free vertical and
horizontal rotations
fitted with three
non return valve
inlets. |
|
|
|
|
|
Top
|
|
Foam Equipments |
|
|
|
 |
Foam Making Branch
Pipe FB5X – Made
from Aluminium Alloy
with 63mm G.M. Male
Inst. Inlet with
Pickup tube – 225
LPM
|
|
|
|
 |
Foam Making Branch
Pipe FB2 – Made from
Aluminium Alloy with
63mm G.M. Male Inst.
Inlet with Pickup
tube.
FB2 – 225 LPM, FB10
– 450 LPM, FB20 –
900 LPM
|
|
|
|
 |
|
Portable
Inline
Inductors
– Made
from
Aluminium
Alloy
with
63MM
G.M.
Male
Inst.
Inlet in
one hand
and
Female
Inst.
Outlet
in other
hand
with
Pick-up
tube.
|
|
Model
|
Nominal Flow lpm (at 7 bars*)
|
Recommended Operating Pressure bars
|
Lenghtmm
|
WeightKgs
|
|
ILI 225
|
225
|
5 - 10
|
440
|
5.5
|
|
ILI 450
|
450
|
5 – 10
|
440
|
5.5
|
|
|
|
|
|
 |
Foam Making Branch
Pipe FB2X – Made
from Aluminium Alloy
with 63mm G.M. Male
Inst. Inlet
|
|
|
|
 |
|
Medium
Expansion
Foam
Branches
– To
produce
stable,
superior
quality
medium
expansion
foam
with
63mm
G.M.
male
inst.
Inlet. (Made
of SS
304 or
Aluminium
Barrel)
|
|
Model
|
Range Mtrs (at 3.5 bars inlet pressure)
|
Nominal Expansion
|
Lenghtmm
|
WeightKgs
|
|
MX 225
|
06
|
1:40
|
530
|
5.0
|
|
MX 450
|
08
|
1:40
|
615
|
6.2
|
|
|
|
|
|
 |
|
High
Expansion
Foam
Generators
– To
Generate
large
amount
of HX
Foam
with
63mm
G.M.
inlet. (Made
of SS
304 or
Aluminium
body/shell)
|
|
Model
|
Output M3/min (at inlet pressure)
|
Nominal Expansion
|
Approx Height mm
|
Approx WeightKgs
|
|
HX
|
47 (at 3.5 bars)
|
1:270
|
610
|
17.0
|
|
Mini Super
|
60 (at 5.5 bars)
|
1:310
|
|
|
|
|
|
|
|
 |
Mobile Foam Trolley
Unit – Portable Foam
Mobile Trolley
fitted with inline
inductor and foam
making branch pipe
(without Hose & AFFF
Liquid). Body is
made of FRP or MS or
SS
Capacity: 100ltrs or
200ltrs
|
|
|
|
 |
Aqueous Film Forming
Foam – Synthetic
based foam compound
mixed with addition
of fluorodensides
processing the
property to create
the film of water
solutions that
floats on top of
non-polar flammable
liquids as per
IS:4989 PART-2 with
ISI Mark (Available
in: 3% or 6% Foam
Compound in 20 ltrs
HDPE Can)
|
|
|
|
 |
Protein Foam
– Based on
Hydrolised Protein
with added foam
stabilizers and
metal salts used to
produce low
expansion foam and
reliable agent for
protection of
hazardous non-polar
flammable liquids as
per IS:4989 PART-1
with ISI Mark.
(Available in: 20
ltrs HDPE Can)
Fluoroprotein Foam
– Specially
formulated by
combining selected
fluorotensides with
protein base and it
produces aqueous
film forming
characteristics as
per IS:4989 PART-3
with ISI Mark
(Available in: 20
ltrs HDPE Can)
Alcohol /
Polar Solvent
Resistant Foam
– Synthetic
polyvalent foam
forming liquid,
Psuedo-plastic
consisting of
surface active
substances and
polymer additives
used for rapid
action on surface
fires with
resistance to
contamination of
Hydrocarbons and to
dehydration of Polar
solvents (Available
in: 20 ltrs HDPE
Can)
High
Expansion Foam
Compound –
A special
composition of
surfactants
solubilizers and
antifreeze agent
designed to produce
foam with low
drainage time,
superior fluidity
and fire resistance.
(Available in: 20
ltrs HDPE Can)
Hazmat Foam
– For
controlling
hazardous vapours
and spills.
(Available in: 20
ltrs HDPE Can)
|
|
|
|
|
|
Top
|
|
Fitting
& Adapters |
|
|
|
 |
Collecting
Breech (GM)
having 1 no. 63mm
Female Inst. Inlet
and 2 nos. 63mm Male
Inst. outlet. As per
IS:905 |
|
|
|
 |
Dividing
Breech
(G.M.) having 1 no.
of 63mm Male Inst.
Inlet & 2 nos. 63mm
Female Inst. Outlet
as per IS:905 |
|
|
|
 |
Controlled
Dividing Breech
(G.M) with Control
Valve having 1 no.
63mm Male Inst.
Inlet & 2 nos. 63mm
Female Inst. Outlet
with control. |
|
|
|
 |
Double Male
Adaptor
(G.M) Inst. of 63mm
as per IS |
|
|
|
 |
Double
Female Adaptor
(G.M) Inst.
of 63mm as per IS |
|
|
|
 |
2 way Fire
Brigade Inlet Cast
Iron (C.I.)
having 2 nos. of
63mm Male Inst. NRV
Inlet with flange. |
|
|
|
 |
3 way Fire
Brigade Inlet Cast
Iron (C.I.)
having 3 nos. 63mm
Male Inst. NRV Inlet
with flange. |
|
|
|
 |
4 way Fire
Brigade Inlet Cast
Iron (C.I.)
having 4 nos. 63mm
Male Inst. NRV Inlet
with flange. |
|
|
|
 |
Non Return
Valve -
Gunmetal with 63mm
male inst. |
|
|
|
 |
ROSETTE
PLATE –
Single leaf rosette
plate either in
chrome plate or
White finish (Also
available in
Stainless Steel) |
|
|
|
|
|
Top
|
|
|
|
|
|
